Invisible Battery
36v 7,0 Ah and 40 Km of autonomy in just 1.16 Kg.
You just need 2 hours to get your battery fully charged.
The minimum distance you can ride at max assistance mode is around 20 km but the maximum at minimum assistance mode is around 75 km.
Battery’s lifespan is around 1500 charges.
Compact Motor
250W rear hub motor 25 Km/h max speed. with 5 assistant levels.
Our bikes have been designed for a safe and reliable urban use, and are perfectly capable of reaching the European maximum permitted speed for these vehicles: 25 km/hr.
The N/m are 42 N/m minimum.
Minimalist Design
Discreet battery autonomy and assistant level display. Super-easy to manage. 100X lights as standard!
8 Speed Gear
8 Speed SunRace RD81, a classic in bike gears, proven durability and robustness.
Pedal assistance
Our pedal assistance is super-easy to manage: whenever you pedal, you get help from the engine, depending on the speed selected (1 to 5). Setting 0 is with no assistance, i.e. a “normal” bike.
Our pedal assistance is based on a system that requires on-going pedalling, but a leisurely and easy pedalling pace is enough for it to receive a boost. Bikes with accelerators are no longer bikes, and for now they are not regulated.
You can use the bike even if the engine and battery are switched off. What’s more, thanks to its lightweight design it does not require more effort to ride, it feels just like a regular bike.
The pedal assistance and battery of our Capri e-bikes have been designed to provide the greatest autonomy. However, it's important to keep in mind that there are several factors that can affect the overall performance of the battery. These factors are:
- Cyclist weight.
- Power supplied by the cyclist.
- Use of different assistance levels.
- Terrain (slope and pavement conditions).
- Tires (pressure and tyre tread).
- Temperature.
Autonomy Performance
The data shown in the graphic has been taken under the following conditions:
- Cyclist weight: 63.6 Kg
- Terrain: "Las Mestas Velodrome". 0% slope.
- Tires: Michelin Dynamic Classic. Pressure: 6 bars (87 P.S.I)
- Frame Geometry: Capri Azur model.
Lightness but made for last
Steel high quality Tig welding in less than 17.5 Kg. Both the engine (which weighs some 800 gr less than any other similar engine) and the battery (which only weighs 1.6 kg) are particularly light elements. We have poured all our efforts into developing these two main components. Furthermore, the other bike components have been chosen following durability, lightness and optimum performance criteria.
The Wheels on the Capri go round and round
High polished double walls aluminium weinnman wheels with 36 inox spokes.
Maximum load supported
The AZUR model (low bar) with Mixte frame is lighter and can carry up to 110 kg; the METZ model (high bar) with a frame prepared for larger people, can carry over 140 kg.
Assembly and packaging
The bike is delivered in a box with the pedals, saddle, handlebars, power and front wheel disassembled. An easy-to-follow assembly video and detailed instructions are included. We recommend that the assembly be carried out by a mechanic.
Does it work in the rain?
Yes, we have tested the bike under all weather conditions. However, we would recommend users to not expose it to rain over a prolonged period of time. It cannot go underwater
Regulatory Information, Capacities, and Intended Use
Annex to the CAPRI Electric Bicycle Product Manual
Regulatory Information, Capacities, and Intended Use
This section details the specifications for use, capacity, and equipment of the bicycle in compliance with current Spanish legislation.
1. Regulatory Compliance
This instruction manual is provided in compliance with the provisions contained in Royal Decree 339/2014, of May 9, (referenced in Article 1.5 of Order PID/9/2023), which establishes the requirements for the marketing and commissioning of bicycles.
In accordance with Annex II, point 2, section f) of the aforementioned Royal Decree, the essential information regarding the use of this bicycle is detailed below.
2. Intended Use and Load Capacity (RD 339/2014)
It is essential that you use this bicycle only for the purposes for which it was designed.
- Intended Use: This bicycle is designed for urban and recreational transport, and for carrying medium loads.
- Number of Seats: This bicycle is approved for one (1) seat (the rider). It allows for the installation of a child restraint system (baby seat) under the conditions described below.
- Maximum Admissible Load (Total Weight): The maximum total load that this bicycle can safely support is 120 kg (264.5 lbs).This weight includes: the rider's weight + all transported cargo (front/rear) + the weight of the child seat itself and the child.
3. Transport Specifications (Cargo and Passengers)
This bicycle is specifically designed for cargo transport and allows for the transport of children under the following specifications:
Cargo Transport:
- Front Carrier: The maximum admissible load on the front carrier is 9 kg (19.8 lbs).
- Rear Carrier: The maximum admissible load on the rear carrier is 25 kg (55.1 lbs).
Passenger Transport (Children):
- This bicycle allows the installation of one (1) approved and homologated child seat, which must be mounted exclusively on the rear carrier.
- The maximum weight supported by the child restraint system (combined weight of the seat + the child) must not exceed 22 kg (48.5 lbs).
- Strictly follow the child seat manufacturer's instructions for correct installation and to ensure safety.
- Important: The weight of the child and the seat is considered part of the rear carrier's load capacity (25 kg) and the total Maximum Admissible Load (120 kg).
4. Lighting System (Order PID/9/2023)
In compliance with Order PID/9/2023, this bicycle is delivered at the time of purchase equipped with the complete regulatory system of lights and reflective devices required by current legislation.
- The lighting system (white front light and red rear light) is integrated and powered directly by the bicycle's main battery.
- It is the user's responsibility to ensure the lights are always on in conditions of low visibility or at night, in accordance with traffic regulations.
